IPB-5000A
6. Discription of Display Screens
6-1
6. Description of Display Screens
(1) Operation Flow
An example of the operation for the use of Welding Power Supply is shown as
follows:
1. Start up IPB-5000A
2. Press MENU Key in the front panel to display MENU Screen
3. Move the cursor ( ) to SCHEDULE Key in MENU Screen and press ENTER
Key to display SCHEDULE Screen
4. Set each value of the followings
(SCH #, TIME, UP SLOPE, DOWN SLOPE, WE1, WE2, TR #)
5. Supply the current for welding (e.g. close Pin No.5 at External Interface in
8.(1)①)
6. Display monitored CURR, VOLT, POWER and RESIST for verifying weld (See
(4)MONITOR Screen)
7. Selection of Several Functions
Set the upper and
lower limit of CURR,
VOLT, POWER and
RESIST for judging
Good or No Good of
weld
(See
(5) COMPARATOR
Screen)
Set Envelope
Waveform for
judging Good or
No Good of weld
(See
(6) ENVELOPE
Screen)
Set Weld Time
and Control
Voltage for
Precheck Current
Supply
(See
(7) PRECHECK
Screen)
Set Weld Stop
Function.
Set Displacement
Check Function.
(See
(8) CONTROL
Screen)
8. Supply the current for welding
9. Stop IPB-5000A
