IPB-5000A
10. External Communication Function
10-1
10.
External
Communication
Function
(1) Introduction
IPB-5000A can be used to set schedules from an externally-connected personal
computor (abreviated as PC) or to read monitored data and several kind of status
data.
(2) Data Transmission
Item Content
Transmission Mode
Select either of the followings at STATUS Screen:
* RS-485, Asynchronous, Half-Duplex
* RS-232C
Transmission Rate
Select either of the followings at STATUS Screen:
9600, 19200, 38400 bps
Data Format Start bit: 1, Data bit: 8, Stop bit: 1, Parity bit: Even
Character Code ASCII
Checksum Data None
Connector
D-Sub 9 pins
Pin Position
In RS-485, 4: SG, 6: RS+, 9: RS-
In RS-232C, 2: RXD, 3: TXD, 5: SG, 7: RTS
