IPB-5000A
10. External Communication Function
10-4
② Bi-directional Communication Mode
(When BI-DIRECTION is selected at COMM CONTROL in STATUS Screen)
Description of Symbols
ID1, ID2: Shows Device No.
Fixed to 2 digits (ID1=Ten’s place, ID2=One’s place)
SH1, SH2, SH3: Shows Schedule No.
Fixed to 3 digits (SH1=Hundred’s place, SH2=Ten’s place,
SH3=One’s place)
CD1, CD2, CD3: Shows Specified Code.
CD1------------Alphabet Classified Symbol
CD2, CD3----Code Classified Number
(See (5)③Specified Code for details of codes.)
No. Description of Command Code
Inquiry about Model and ROM
Version
# Device No. I
1
Example: Model of Device No. 1 and ROM Version, V00-00A
From Host PC to IPB-5000A
# ID1 ID2 I CR LF
(# 0 1 I CR LF)
From IPB-5000A to Host PC
! ID1 ID2 : IPB5000A , ROM Version CR LF
(! 0
1 : I P B 5 0 0 0 A , V 0 0 - 0 0 A CR LF)
Note) When “*”is set for both ID1 and ID2, all connected devices
respond. In the case that all devices respond, the time-lag of
response is 100ms multiplied by ID No. (Device No.).
Reading of Schedule Data # Device No. R Schedule No. *
2
Example: Read all data of Schedule No. 8 in Device No. 01.
From Host PC to IPB-5000A
# ID1 ID2 R SH1 SH2 SH3 * CR LF
(# 0 1 R 0 0 8 * CR LF)
From IPB-5000A to Host PC
! ID1 ID2 SH1 SH2 SH3 : Data String CR LF
(! 0 1 0 0 8 : Data CR LF)
Note) When Schedule No. (SH1, SH2, SH3) is “000”, the basic set
conditions (Conditions set at 6.(8)STATUS Screen) are read.
See 5.①Order Table of Schedule Data for the data order of a
Schedule.
To Next Page
