10. External Communication Function
10-5
No. Description of Command Code
Setting of Schedule Data # Device No. W Schedule No. : Data
3
Example: Set data on Schedule No. 8 in Device No. 01.
From Host PC to IPB-5000A
# ID1 ID2 W SH1 SH2 SH3 : Data String CR LF
(# 0 1 W 0 0 8 : Data String CR LF)
From IPB-5000A to Host PC
! ID1 ID2 SH1 SH2 SH3 : Data String CR LF
(! 0 1 0 0 8 : Data String CR LF)
Note) Each data is separated with “,”.
When Schedule No. is “000”, the basic set conditions
(Conditions set at 6.(9)STATUS Screen) are set.
See 5.①Order Table of Schedule Data for the data order of a
Schedule.
The set data is returned as confirmation from IPB-5000A.
When data outside the range is set, the last data before setting
is exactly returned.
Reading of Specified Item
# Device No. R Schedule No.
Specified Code
4
Example: Read 2nd. Weld Time (WE2) (23ms) on Schedule No. 31 in
Device No. 01.
From Host PC to IPB-5000A
# ID1 ID2 R SH1 SH2 SH3 CD1 CD2 CD3 CR LF
(# 0 1 R 0 3 1 T 0 7 CR LF)
From IPB-5000A to Host PC
! ID1 ID2 SH1 SH2 SH3 : データ CR LF
(! 0 1 0 3 1 T 0 7 : 0 2 3 . 0 m s CR LF)
Setting of Specified Data
# Device No. W Schedule No.
Specified Code, Data
5
Example: Set the current of 1st. Weld Time (WE1) on Schedule No. 31
in Device No. 01 to 3.2kA.
From Host PC to IPB-5000A
# ID1 ID2 W SH1 SH2 SH3 CD1 CD2 CD3 CR LF
(# 0 1 W 0 3 1 H 0 1 : 3 . 2 0 k A CR LF)
From IPB-5000A to Host PC
! ID1 ID2 SH1 SH2 SH3 : Data CR LF
(! 0 1 0 3 1 H 0 1 : Data CR LF)
Note) The set data is returned as confirmation from IPB-5000A.
When data outside the range is set, the last data before setting is
exactly returned.
To Next Page
