10. External Communication Function
10-8
(5) Data Code Table
① Order Table of Schedule Data
1) Specific Data in accordance with Schedule No. (Schedule No.: 001 to 127)
Orde
r
Character
String
Item
Range of
Setting
Increment/
Decrement
1 nnnn, Squeeze Time 0000 to 9999 1ms
2 nnn.n, Upslope 1 Time 000.0 to 100.0 0.2ms
3 nnn.n, 1st. Weld Time 000.0 to 100.0 0.2ms
4 nnn.n, Downslope 1 Time 00.0 to 100.0 0.2ms
5 nn.n, Cool Time 00.0 to 99.8 0.2ms
6 nnn.n, Upslope 2 Time 000.0 to 100.0 0.2ms
7 nnn.n, 2nd. Weld Time 000.0 to 100.0 0.2ms
8 nnn.n, Downslope 2 Time 000.0 to 100.0 0.2ms
9 nnn, Hold Time 000 to 999 1ms
10 n.nn, WE1 Current Setting 0.20 to 6.00 0.01kA
11 n.nn, WE2 Current Setting 0.20 to 6.00 0.01kA
12 n.nn, WE1 Voltage Setting 0.30 to 9.99 0.01V
13 n.nn, WE2 Voltage Setting 0.30 to 9.99 0.01V
14 nn.n, WE1 Power Setting 00.2 to 20.0 0.01kW
15 nn.n, WE2 Power Setting 00.2 to 20.0 0.01kW
16 n, Transformer No. 1 to 5 ----
17 nn, Control Method in WE1 00 to 03
18 nn Control Method in WE2 00 to 03
00: CURR
01: VOLT
02: COMB
03: POWER
2) Common Data
Orde
r
Character
String
Item Notes
1 nn,
Selection of
Welding Transformer
01: ITD-360A6
02: ITB-780A6
2 nn, Weld Time
00: Slope Time Excluded
01: Slope Time Included
3 nn,
Selection of
Start-up Condition
Stabilizing Time
00: 1ms 01: 5ms
02: 10ms 03: 20ms
4 nn,
Selection of
Start-up Input Signal
Type
00: No Self-sustaining
01: Self-sustaining from Weld
Time
02: Self-sustaining from
Squeeze Time
