IPB-5000A
10. External Communication Function
10-10
③ Specified Code
1) Specifying of Weld Sequence (T)
Dimension of “ms” is added to each data.
Specified
Code
Item
Range of
Setting
Increment/
Decrement
T01 Squeeze Time 0000ms to 999ms 1ms
T02 Upslope 1 Time 000.0ms to 100.0ms 0.2ms
T03 1st. Weld Time 000.0ms to 100.0ms 0.2ms
T04 Downslope 1 Time 000.0ms to 100.0ms 0.2ms
T05 Cool Time 00.0ms to 99.8ms 0.2ms
T06 Upslope 2 Time 000.0ms to 100.0ms 0.2ms
T07 2nd. Weld Time 000.0ms to 100.0ms 0.2ms
T08 Downslope 2 Time 000.0ms to 100.0ms 0.2ms
T13 Hold Time 000ms to 999ms 1ms
T15 Precheck Weld Time 00.0ms to 10.0ms 0.2ms
2) Setting of Control Current, Voltage and Power (H)
Specified
Code
Item
Range of
Setting
Increment/
Decrement
H01 WE1 Current Setting 0.20kA to 6.00kA 0.01kA
H02 WE2 Current Setting 0.20kA to 6.00kA 0.01kA
H04 WE1 Voltage Setting 0.50V to 9.99V 0.01V
H05 WE2 Voltage Setting 0.50V to 9.99V 0.01V
H06 WE1 Power Setting 00.2kW to 20.0kW 0.1kW
H07 WE2 Power Setting 00.2kW to 20.0kW 0.1kW
H21 Precheck Voltage Setting 0.00V to 9.99V 0.01V
3) Setting of Monitor Upper/Lower Limit (N)
Specified
Code
Item Range of Setting
Increment/
Decrement
N00 WE1 Monitor Current Upper Limit 0.00kA to 9.99kA 0.01kA
N01 WE1 Monitor Current Lower Limit 0.00kA to 9.99kA 0.01kA
N02 WE2 Monitor Current Upper Limit 0.00kA to 9.99kA 0.01kA
N03 WE2 Monitor Current Lower Limit 0.00kA to 9.99kA 0.01kA
N06 WE1 Monitor Voltage Upper Limit 0.00V to 9.99V 0.01V
N07 WE1 Monitor Voltage Lower Limit 0.00V to 9.99V 0.01V
(Continued)
