IPB-5000A
10. External Communication Function
10-11
Specified
Code
Item Range of Setting
Increment/
Decrement
N08 WE2 Monitor Voltage Upper Limit 0.00V to 9.99V 0.01V
N09 WE2 Monitor Voltage Lower Limit 0.00V to 9.99V 0.01V
N12 WE1 Monitor Power Upper Limit 00.0kW to 99.9kW 0.1kW
N13 WE1 Monitor Power Lower Limit 00.0kW to 99.9kW 0.1kW
N14 WE2 Monitor Power Upper Limit 00.0kW to 99.9kW 0.1kW
N15 WE2 Monitor Power Lower Limit 00.0kW to 99.9kW 0.1kW
N24
WE1 Monitor Resistance Upper
Limit
00.0m* to 99.9m*
0.1m*
（Note）
N25
WE1 Monitor Resistance Lower
Limit
00.0m* to 99.9m* 0.1m*
N26
WE2 Monitor Resistance Upper
Limit
00.0m* to 99.9m* 0.1m*
N27
WE2 Monitor Resistance Lower
Limit
00.0m* to 99.9m* 0.1m*
N42
Resistance Precheck Monitor
Current Upper Limit
0.00kA to 9.99kA 0.01kA
N43
Resistance Precheck Monitor
Current Lower Limit
0.00kA to 9.99kA 0.01kA
N70
Setting of Current PEAK／RMS
0:PEAK/1:RMS --
N72
Setting of Voltage PEAK／RMS
0:PEAK/1:RMS --
N73 Displacement Delay Time 0 to 999ms
N74 Workpiece Detect Upper Limit
N75 Workpiece Detect Lower Limit
-29.999 to
+29.999mm
0.001mm
(Note) The symbol “*” means Ω.
4) Reading of Monitor Judgment Results (J)
Specified
Code
Item Contents
J00
Judgment Result of Current
Upper/Lower Limit
J03
Judgment Result of Voltage
Upper/Lower Limit
J06
Judgment Result of Power
Upper/Lower Limit
J12
Judgment Result of
Resistance Upper/Lower
Limit
J21
Judgment Result of
Precheck Current
a. Judgment Result Data:
‘N’ means OK.
‘L’ means Lower Limit NG.
‘H’ means Upper Limit NG.
b. Judgment of Weld Workpiece
Setting Status in Precheck:
‘N’ means OK.
‘E’ means NG.
c. Only when the last
current-supplied Schedule is
selected, the judgment result
of the Schedule is displayed.
