IPB-5000A
10. External Communication Function
10-12
5) Reading of Monitored Value (M)
Specified Code Item Display (n=0 to 9)
M00 WE1 Monitor Current (PEAK Value) n.nnkA
M01 WE2 Monitor Current (PEAK Value) n.nnkA
M03 WE1 Monitor Voltage (PEAK Value) n.nnV
M04 WE2 Monitor Voltage (PEAK Value) n.nnV
M06 WE1 Monitor Power nn.nkW
M07 WE2 Monitor Power nn.nkW
M12 WE1 Monitor Resistance
nn.nm*（Note）
M13 WE2 Monitor Resistance nn.nm*
M21 Precheck Monitor Current n.nnkA
M30 WE1 Monitor Current (RMS Value) n.nnkA
M31 WE2 Monitor Current (RMS Value) n.nnkA
M32 WE1 Monitor Voltage (RMS Value) n.nnV
M33 WE2 Monitor Voltage (RMS Value) n.nnV
M65 Work Detecting Displacement +/-nn.nnnmm
(Note) The symbol “*” means Ω.
6) Reading of Items relating with Envelop (V)
Specified
Code
Item Contents
V00 Envelop Type
0: Current, 1: Voltage,
2: Power, 3: Resistance
4: Displacement
V01
Interval
Start Time
nnnnnms
V02 Interval End Time nnnnnms
V03
Offset
Upper Limit (+)
n.nnkA/n.nnV/nn.nkW/nn.nm*/nn.nnnmm
（Note）
V04
Offset
Lower Limit (-)
n.nnkA/n.nnV/nn.nkW/nn.nm*/nn.nnnmm
（Note）
V05 Envelop ON/OFF
0：OFF, 1：ON
(Note) The symbol “*” means Ω.
7) Setting of Items relating with Counter (C)
Specified
Code
Item Contents
C00
Reading of
Displayed Counter
C14 Counter Mode
0: TOTAL, 1: GOOD,
2: WORK
C05 Preset (TOTAL/GOOD)
C06 Preset (WORK)
C07 Preset (WELD)
C11 Counter Reset (All Counters)
