IPB-5000A
10. External Communication Function
10-13
8) Setting of Initial Setting Condition (P)
pecified
Code
Item Contents
P01
Schedule Select
Method
00: Closed Circuit of Schedule Select
Terminal (No Parity)
01: Closed Circuit of Schedule Select
Terminal (Parity Valid)
02: Select on Front Panel
P02
Start Signal Stabilizing
Time (Delay Time)
00: 1ms 01: 5ms、
02: 10ms 03: 20ms
P03
End Signal Output
Time
00: 10ms 01: 100ms
02: While Start Signal Output
P04
Self-sustaining Time at
Starting
00: No Self-sustaining
01: Self-sustaining from Weld Time
02: Self-sustaining from Squeeze Time
P10
Weld ON/OFF
00: Weld Off
01: Weld ON
P40
Weld Transformer
00: ITE-142A6 01: ITD-360A6
02: ITB-780A6
P41
Monitor Value Display
Mode
00: Slope Time Excluded
01: Slope Time Includes
P43
Transformer
Scan Mode
00: OFF 01: ON 02: 1-2
03: 1-3 04: 1-4 05: 1-5
P45
No-current Monitor
Start Time
00 to 10
(Dimension “ms” Eliminated)
P46
Pulse Width Monitor
Start Time
00 to 10
(Dimension “ms” Eliminated)
P47
NG Terminal Mode
Setting
00: Open Circuit at NG
01: Closed Circuit at NG
P48
READY Output Mode
Setting
00: ON at Weld ON
01: ON at Power ON
P49
Monitor Value
Calculation Method
00: Normal 01: Fast
P52
Weld Time
00: Slope Time Excluded
01: Slope Time Included
9) Reading of Error and Error Reset (E)
Specified Code Item
E00 Error Reset
E99 Error Reading
See 12.Error Codes for details of Codes E01 to E25.
