IPB-5000A
6. Discription of Display Screens
6-21
(c) COUNTER
Set the mode of Counter.
TOTAL Count-up (increment of +1) is done despite the result of the
judgment in monitoring when the current is supplied.
Judgment in Monitor Counting Manner
GOOD
Count-up
CAUTION
Count-up
NG
Count-up
GOOD Count-up is done if the judgment is GOOD in current-supplied
monitoring.
Judgment in Monitor Counting Manner
GOOD
Count-up
CAUTION
No Count-up
NG
No Count-up
WORK Count-up is not done if the judgment is NG in current-supplied
monitoring.
Judgment in Monitor Counting Manner
GOOD
WELD Counter counts-up.
WORK Counter counts-up (increment of
+1) when WELD Counter reached the
set value.
CAUTION
WELD Counter counts-up.
WORK Counter counts-up (increment of
+1) when WELD Counter reached the
set value.
NG
WELD Counter does not count-up.
WELD Counter is reset to 0 (zero) when
NG is reset.
WORK Counter does not count-up.
Note: The period for retaining the memory of counted numbers is
approximately 10 days since the day when a power supply is turned
off at latest.
(d) PRESET (TOTAL/GOOD)
Input the preset value of TOTAL/GOOD Counter.
(e) PRESET (WORK)
Input the preset value of WORK Counter.
(f) PRESET (WELD)
Input the preset value of WELD Counter.
(g) BACK
Displays ② STATUS (2/2) Screen of the previous page.
