IPB-5000A
9. Time Chart
9-2
② In the case of DATA OUTPUT at COMM CONTROL,
Communication data output time is included.
Calculation Mode Setting (CALCULATION MODE)
Communication Speed
Setting
(COMM SPEED)
NORMAL FAST
9600bps
330ms Max. 280ms Max.
19200bps
275ms Max. 225ms Max.
38400bps
245ms Max. 195ms Max.
c: Screen Display Time and Start Signal Standby Time
① Screen Display Time
Screen Display Time is the period required from the end of END Signal
Output for screen displaying.
It is 355ms Max. However, it changes in accordance with the type of screens
as follows.
Display Screen Period
SCHEDULE 205ms Max.
MONITOR
(The next coming signal makes
the screen display cancelled in
MONITOR Screen.)
0ms
COMPARATOR 220ms Max.
ENVELOPE 355ms Max.
PRECHECK 60ms Max.
CONTROL 55ms Max.
STATUS 0ms
② Start Signal Standby Time
It is the period necessary for opening Start Input Signal.
After Screen Display Time elapsed, it is required to open Start Input for 10ms
or more.
d: CAUTION Output is switched to OFF at the coming input of Start Signal.
To Next Page
