MKS 640A/641A - Down Port Version; Figure 3: Top View of the down Port Type 640 Controller; Figure 4: Front and Side View of the down Port Type 640

Chapter Two: Installation Dimensions
19
Down Port Version
Interface Connector
Figure 5: Top View of the Down Port Type 640 Controller
5.522
(140.26)
0.985 +
0.020
(25.02 +
0.51)
0.020
(0.51)
Inlet
Outlet
1.476 +0.025
(37.49 +
0.63)
Figure 6: Front and Side View of the Down Port Type 640
