Mx2wire Media Converter (MX-2wire-Set-PW)
The Mx2wire system allows you to set up an Ethernet
network with PoE via two-wire cables of up to 500 m in
length. This allows an existing two-wire analog telephone
line to be connected to a 10/100 Mbps Ethernet device
(for example, PC, WLAN, IP camera, IP telephone, or IP
door station). The achievable data rate is up to 30 Mbps.
Around 15 Mbps can be reached even with 500 m of
antenna cable.
An identical Mx2wire device is placed at the beginning
and the end of the line. Configuration as sender or receiver
is automatic. The Mx2wire units are supplied with power
by the feeding network cable. The connected devices
are supplied with up to 7 watts over PoE, as the injected
PoE signal is transmitted parallel to the network signal.
Mx2wire is delivered in the standard wall outlet frame
in dierent designs, however, it can also be used with
the available surface-mounted socket that is included.
