1. Establish a connection to the camera as described in Section 3.2 First Images And
The Most Important Settings. The live image from the camera should be visible on
the computer monitor.
2.
so that you can easily
turn and tilt the camera.
3. Display the desired camera section on the com-
puter monitor, then turn and tilt the camera until
you have found the best position and sharpness.
Retighten the screws of the VarioFlex mount to
prevent the position of the camera from changing.
4. If required, clean the lens cover using a clean,
lint-free cotton cloth.
The M24M-Sec with hemispheric L11 lens allows the cor-
rection of an uneven image horizon via OnScreenControl
that was possibly caused by the installation position. The
image horizon is turned by up to 30 degrees clockwise
or counterclockwise and can be optically restraightened
by clicking on the icons (see image).
HORIZON CORRECTION
Rotate image up to -30°
