M62 Professional IP Deskphone Administrator’s Manual
- 72 -
Authorized ID
Set SIP registrar authorized ID.
Authorized Password
Set SIP registrar authorized password.
Locating SIP Server
Enable locating SIP server.
Enum Suffix
Set Enum Suffix.
End Dial on #
Enable end dial on #.
DTMF Type
Select DTMF type (None, Tone, RFC2833, SIP-INFO).
RFC2833 Payload
Set RFC2833 payload length (96 ~ 127).
SIP Settings:
Session Expires (Sec.)
Set expire time for session.
MIN SE (Sec.)
Set minimum session expiration time. It will notify server the
minimum expiration time that you accepted in negotiation
state. It is conveyed in the Min-SE header in the initial
INVITE request.
SIP 100rel Support
Turn on SIP 100rel Support.
Optional SIP Header:
Optional SIP Header1
Set first optional SIP header.
Optional SIP Header2
Set second optional SIP header.
RTP Parameters:
RTP Port Base
Set port base for RTP (Real-time Transport Protocol).
Enable Statistic
Enable statistic RTP server.
