Monarch 9906 - Page 56

3-12 Packet Reference Manual
Bar Code
Type
Density
Selector
Density
(% or cpi)
Narrow
Element
(dots/mils)
Narrow to
Wide Ratio
Data
Length
Appearance
Codes
Char
Set
CODE 93 3
4
5
7
10
3.7
4.5
5.6
7.5
11.2
6/29.6
5/24.6
4/19.7
3/14.8
2/9.9
N/A 0 to 2710 8 00H to7FH
MSI 4
5
7
4.2
5.6
7.2
4/19.7
3/14.8
2/9.9
1:2.0
1:2.0
1:2.5
0 to 14 8 0 to 9
POSTNET
0 (fixed
at 4.3
cpi)
24/118.2 10/49.3 4/19.7
(5 dot gap)
0,5,6,9 or
11
8 0 to 9
Intelligent
Mail
0 (fixed
at 4.3
cpi)
24/118.2 10/49.3 4/19.7
(5 dot gap)
0,5,6,9 or
11
8 0 to 9
MaxiCode
7
N/A N/A N/A 99 8 00H to
FFH
Bar Code
Type
Density
Selector
Element
Width
(dot/mils)
Row Height
(dots/mils)
Aspect
Ratio
Data
Length
Appearance
Codes
Char Set
PDF417 1
2
3
4
5
6
7
8
9
2/9.8
2/9.8
2/9.8
3/14.8
3/14.8
3/14.8
4/19.7
4/19.7
4/19.7
2/9.8
4/19.7
6/29.6
3/14.8
6/29.6
9/44.3
4/19.7
8/39.4
12/59.1
1:1
1:2
1:3
1:1
1:2
1:3
1:1
1:2
1:3
0 to 2709 8 00H toFFH
203/300 DPI Bar Code Densities
Bar Code Type Density Selector Data Length
Quick Response
(QR Code) Models 1 and 2
0
Model 1: 0 - 1167 Numeric;0 - 707 Alphanumeric;0 - 486 (8-bit);
0 - 299 (Kanji)
Model 2: 0 - 2710 Numeric, Alphanumeric and 8-bit; 0 - 1817 Kanji
Note: Values in bold indicate the default.
