Defining Fields 3-11
203 DPI Bar Code Densities
Bar Code
Type
Density
Selector
Density
(% or cpi)
Narrow
Element
(dots/mils)
Narrow to
Wide
Ratio
Data
Length
Appearance
Codes
Char
Set
UPCA
+2/+5
Price CD
2
4
76%
114%
2/9.9
3/14.8
N/A 11 or 12
14/17
1, 5, 6, 7 or
8
0 to 9
UPCE+2/+5
2
4
76%
114%
2/9.9
3/14.8
N/A 6 or 7
9/12
1, 5, 6, 7 or
8
0 to 9
EAN8+2/+5
2
4
76%
114%
2/9.9
3/14.8
N/A 7 or 8
10/13
1, 5, 6, 7 or
8
0 to 9
EAN13+2/+
5
Price CD
2
4
76%
114%
2/9.9
3/14.8
N/A 12 or 13
15/18
1, 5, 6, 7 or
8
0 to 9
Interleaved
2 of 5or
I2of5with
Barrier Bar
1
2
3
4
5
6
7
8
9
10
11
12
13
1.1
2.1
3.2
4.2
5.6
6.3
7.5
8.8
9.6
11.2
11.0
12.7
14.5
21/103.4
12/59.1
7/34.5
6/29.6
4/19.7
4/19.7
3/14.8
3/14.8
3/14.8
2/9.9
2/9.9
2/9.9
2/9.9
1:3.0
1:2.5
1:3.0
1:2.5
1:3.0
1:2.5
1:3.0
1:2.3
1:2.0
1:3.0
1:3.0
1:2.5
1:2.0
0 to 2710 8 0 to 9
(Code 39 or
MOD43
(Extended
Code 39)
1
2
3
4
6
7
11
12
20
1.4
1.7
3.5
4.2
6.3
7.0
3.9
12.7
3.0
10/49.3
8/39.4
4/19.7
3/14.8
2/9.9
2/9.9
4/19.7
1/4.9
5/24.6
1:2.5
1:2.5
1:2.5
1:3.0
1:3.0
1:2.5
1:2.0
1:3.0
1:2.2
0 to 2710 8 SPACE
$%*+-./
0 to 9
A to Z
Codabar
(NW7)
2
3
4
5
7
8
9
2.1
3.0
4.6
5.1
8.4
9.2
10.1
8/39.4
6/29.6
4/19.7
4/19.7
2/9.9
2/9.9
2/9.9
1:3.0
1:2.5
1:2.5
1:2.0
1:3.0
1:2.5
1:2.0
0 to 26 8 $+-./
0 to 9
a to d
Code 128
or Code
16K
20
4
6
3.5/7.0
4.4/8.7
5.8/11.7
8.7/17.5
5/24.6
4/19.7
3/14.8
2/9.9
N/A 0 to 2710 8 00H to
7FH
Note: The start (*) and stop (+) characters are automatically added for Code 39.
Code 93, density 12, produces a one-dot narrow bar. This density is
intended for special U.S.P.S. ACT-tag applications only. Synthetic
supplies are recommended to produce scannable bar codes.
