3-16 Packet Reference Manual
300 DPI Bar Code Densities
Bar Code
Type
Density
Selector
Density
(% or cpi)
Narrow
Element
(dots/mils)
Narrow to
Wide Ratio
Data
Length
Appearance
Codes
Char Set
CODE 93 3
4
5
7
10
3.7
4.8
5.6
8.3
11.1
9/30.0
7/23.4
6/20.0
4/13.3
3/10.0
N/A 0 to 2710 8 00H to 7FH
MSI 4
5
7
4.2
6.2
7.5
6/20.0
4/13.3
3/10.0
1:2.0
1:2.0
1:2.3
0 to 2710 8 0 to 9
POSTNET
0
(fixed at
4.3 cpi)
24/118.2 10/49.3 6/20.0
(5 dot gap)
0, 5, 6, 9
or 11
8 0 to 9
Intelligent
Mail
0
(fixed at
4.3 cpi)
24/118.2 10/49.3 4/19.7
(5 dot gap)
0,5,6,9 or
11
8 0 to 9
MaxiCode
7
N/A N/A N/A 99 8 00H to FFH
Bar Code
Type
Density
Selector
Element
Width
(dot/mils)
Row Height
(dots/mils)
Aspect
Ratio
Data
Length
Appearance
Codes
Char Set
PDF417 1
2
3
4
5
6
7
8
9
3/10.0
3/10.0
3/10.0
4/13.3
4/13.3
4/13.3
6/20.0
6/20.0
6/20.0
3/10.0
6/20.0
9/30.0
4/13.3
9/30.0
12/40.0
6/20.0
12/40.0
18/60.0
1:1
1:2
1:3
1:1
1:2
1:3
1:1
1:2
1:3
0 to 2709 8 00H to FFH
300 DPI Bar Code Densities
Bar Code Type Density
Selector
Narrow Element
(dots/mils)
Data Length Char Set
GS1 DataBar
2
3
4
5
6
7
8
3/9.8
4/13.1
5/16.4
7/23
8/26.2
10/32.8
11/36.1
0 to 2710 00H to
FFH
Aztec
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0.0100
0.0133
0.0167
0.0233
0.0266
0.0333
0.0366
0.0433
0.0466
0.0533
0.0566
0.0633
0.0666
0.0733
0 to 2710 00H to
FFH
Note: Values in bold indicate the default.
