B9. height Bar code height, in 1/100 inches, 1/10 mm, or dots. Minimum values:
Height Bar Code Type Description
0
Aztec
Intelligent Mail
PDF 417
PostNet
MaxiCode
These bar codes have a fixed height. Use 0.
0
Data Matrix
QR Code
The printer determines the size of the symbol, but the user’s
scanner determines the functional size (minimum height) of
the symbol. Small Data Matrix and QR Codes may not be
scannable. The Data Matrix and QR Code’s height depends
on the number entered for this parameter. For example, if
you select 80, the symbol could be smaller than 0.80," but it
will not be greater than the amount specified in this
parameter. The symbol arranges the data according to rows
and columns within the specified height.
0
GS1 DataBar This height is only for the linear bar code used with
UCC/EAN family types listed in B13. Use 0 for all other GS1
DataBar types.
20
Code 93
20 is the default for Code 93.
40
UPCA/UPCE/EAN
I 2of5
Codabar
Code 39
Code 128
MSI
40 is the default for UPCA/UPCE/EAN, I 2of5, Codabar, Code
39, Code 128, and MSI.
B10. text Appearance of text with bar code. Options:
Appear. Bar Code Type Description
0
MaxiCode
QR Code
MaxiCode Mode 0 (obsolete)
QR Code Model 2
1
UPC/EAN
QR Code
No check digit or number system
QR Code Model 1
2
MaxiCode
QR Code
MaxiCode Mode 2 (Numeric Postal Code)
QR Code Model 2
3
MaxiCode MaxiCode Mode 3 (Alphanumeric Postal Code)
5
UPC/EAN Number system at bottom, no check digit
6
UPC/EAN Check digit at bottom, no number system
7
UPC/EAN Check digit and number system at bottom (default)
8
MaxiCode
All other bar
codes
MaxiCode (auto detect modes 0, 2, 3, or for compressed
data) default
No text, bar code only (default)
