6 Function Code Table NICE5000 User Manual
- 100 -
Function
Code
Parameter Name Setting Range Default
Unit
Property
F1-02
Rated motor
voltage
50–600
380
V
★
F1-03
Rated motor
current
0.00–655.00
25
A
★
F1-04
Rated motor
frequency
0.00–99.00
50
Hz
★
F1-05
Rated motor speed 0–3000
1460
RPM
★
F1-06
Stator resistance 0.000–65.000
0.000
Ω
★
F1-07
Rotor resistance 0.000–65.000
0.000
Ω
★
F1-08
Leakage
inductance
0.00–650.00
2.34
mH
★
F1-09
Mutual inductance 0.1–3000.0
66.6
mH
★
F1-10
Magnetizing
current
0.01–650.00
10.7
A
★
F1-11
Auto-tuning mode
0: No operation
1: With-load auto-tuning
2: No-load auto-tuning
3: Current loop parameter
identication (only for
synchronous motor)
0
-
★
F1-12
Angle-free auto-
tuning function
selection
Bit1: Angle-auto-tuning-free
0
-
★
F1-13
Motor auto-tuning
current
30–150
60
%
★
F1-15
Shaft Q inductance
(torque)
0.00–650.00
3.00
mH
★
F1-16
Shaft D inductance
(excitation)
0.00–650.00
3.00
mH
★
F1-17
Back EMF 0–65535
0
-
★
F1-25
Motor type
0: Asynchronous motor
1: Synchronous motor
1
-
★
Group F2: Vector control parameters
F2-00
Speed loop
proportional gain
KP1
0–100
40
-
★
F2-01
Speed loop integral
time TI1
0.01–10.00
0.60
s
★
F2-02
Switchover
frequency 1
0.00 to F2-05
2.00
Hz
★
