6 Function Code Table NICE5000 User Manual
- 104 -
Function
Code
Parameter Name Setting Range Default
Unit
Property
F4-117
Low byte of oor
height 54
0–65535
0
Pulses
★
F4-118
High byte of oor
height 55
0–65535
0
Pulses
★
F4-119
Low byte of oor
height 55
0–65535
0
Pulses
★
Group F5: Terminal function parameters
F5-00
Load cell input
selection
0: Invalid
1: CTB digital input
2: CTB analog input
3: MCB analog input
2
-
★
F5-01
X1 function
selection
000: Invalid
001: Up leveling signal
002: Down leveling signal
003: Door zone signal
004: Safety circuit feedback signal
005: Door lock circuit feedback
signal
006: RUN contactor feedback
signal
007: Brake contactor/Brake
detection switch feedback signal
(allow repeat selection)
108: Inspection signal (only NC)
009: Inspection up signal
010: Inspection down signal
011: Fire emergency signal
112: Up limit signal (only NC)
113: Down limit signal (only NC)
014: Overload signal
015: Full-load signal
116: Up slow-down 1 signal (only
NC)
117: Down slow-down 1 signal
(only NC)
118: Up slow-down 2 signal (only
NC)
119: Down slow-down 2 signal
(only NC)
(To be continued)
101
-
★
F5-02
X2 function
selection
102
-
★
F5-03
X3 function
selection
116
-
★
F5-04
X4 function
selection
117
-
★
F5-05
X5 function
selection
118
-
★
F5-06
X6 function
selection
119
-
★
F5-07
X7 function
selection
0
-
★
F5-08
X8 function
selection
0
-
★
F5-09
X9 function
selection
4
-
★
F5-10
X10 function
selection
5
-
★
F5-11
X11 function
selection
106
-
★
F5-12
X12 function
selection
107
-
★
