7 Description of Function Codes NICE5000 User Manual
- 140 -
Bit Function Description Remarks
Bit6
Stop position
1
Stop at the base oor
-
0
Stop at nearest landing oor
-
Bit7
Startup
compensation
1
Startup torque compensation valid in
emergency evacuation running
-
0
Invalid
-
Bit8 to Bit15: reserved
Function Code Parameter Name Setting Range Default Unit Property
F3-15
Normal speed emergency
evacuation speed
0.080–0.500
0.080 m/s ★
F3-16
Acceleration rate at
emergency evacuation
0.500–2.000
0.500 m/s
2
★
It is used to set the acceleration rate at emergency evacuation.
Function Code Parameter Name Setting Range Default Unit Property
F3-17
Normal speed emergency
evacuation times
0–10
0 - ★
It is used to set the maximum normal speed emergency evacuation times allowed.
This parameter is valid only when normal speed emergency evacuation is allowed (F3-14
Bit2 = 1).
Function Code Parameter Name Setting Range Default Unit Property
F3-18
Zero-speed control time at startup 0.000–1.000
0.200 s ★
F3-19
Brake release delay 0.000–1.5.000
0.600 s ★
F3-20
Zero-speed control time at end 0.000–1.000
0.300 s ★
F3-21
Brake apply delay 0.200–1.500
0.200s s ★
These parameters are used to set the time related to the zero-speed holding current output
and braking action delay.
F3-18 (Zero-speed control time at startup) specifies the time from output of the RUN
contactor to output of the brake contactor, during which the controller performs excitation on
the motor and outputs zero-speed current with large startup torque.
F3-19 (Brake release delay) species the time from the moment when the system sends
the brake release command to the moment when the brake is completely released, during
which the system retains the zero-speed torque current output.
F3-20 (Zero-speed control time at end) specifies the zero-speed output time when the
running curve ends.
F3-21 (Brake apply delay) species the time from the moment when the system sends the
brake apply command to the moment when the brake is completely applied, during which
the system retains the zero-speed torque current output.
