NICE5000 User Manual 7 Description of Function Codes
- 139 -
It is used to set the elevator speed during inspection and shaft auto-tuning.
Function Code Parameter Name Setting Range Default Unit Property
F3-12
Low speed emergency
evacuation speed
0.080 to F3-11
0.100 m/s ★
It is used to set the elevator speed ruing low speed emergency evacuation.
Function Code Parameter Name Setting Range Default Unit Property
F3-13
Base oor verication speed 0.100 to F0-04
0.500 m/s ★
It is used to set the elevator speed for base oor verication.
It is valid when the function of returning to base floor for verification at too large pulse
deviation is enabled (F6-09 Bit1 = 1).
Function Code Parameter Name Setting Range Default Unit Property
F3-14
Emergency evacuation
function selection
0–65535
32 - ★
It is used to select the emergency evacuation-related functions. Each bit of the function code
denes a function, as described in the following table.
Bit Function Description Remarks
Bit0
Emergency
evacuation exit
mode
1
Shorting stator braking mode
Shorting stator braking mode: Upon power
failure, EPS is used, the motor stator is
shorted, and the brake is automatically
released, making the car move slowly
under the effect of the weighing difference
between the car and the counterweight.
-
0
EPS
-
Bit1
Low voltage
drive
1
48 VDC
-
0
220 VAC and above
-
Bit2
Normal speed
emergency
evacuation
1
Allowed This function is enabled
when the EPS capacity
is sufcient and the
voltage is high enough.
0
Forbidden
Bit3
Door open at
single leveling
signal
1
Allowed
The door opens when a
single leveling signal is
active.
0
Forbidden
Bit4
Direction
determine
mode
0
Automatically
calculating
the direction
0
Load
direction
determining
based on
half-load
signal
1
Landing
at
nearest
oor
-
Bit5 0 1 0 -
