NICE5000 User Manual 3 Mechanical and Electrical Installation
- 53 -
The HCB-B provides four relay outputs, K1, K2, K3, and K4, provided by CN2 terminals.
Table 3-13 Relay output and pin denition of CN2
Relay CN2 Pin Common Function Description
K1 A1 AM Up arrival indicator
K2 A2 AM Down arrival indicator
K3 B1 BM Up arrival gong
K4 B2 BM Down arrival gong
The DIP switch S1 is used to set the floor address of the HCB-B, as described in the
following table.
Table 3-14 Floor address setting by S1
S1 Floor Address Setting, Range: 0–63
S1.1
Floor address selection Bit0
S1.2
Floor address selection Bit1
S1.3
Floor address selection Bit2
S1.4
Floor address selection Bit3
S1.5
Floor address selection Bit4
S1.6
Floor address selection Bit5
The DIP switch S2 is used to select the function of the HCB-B, as described in the following
table.
Table 3-15 S2 description
S2 Function
S2.1
Modbus termination resistor setting
S2.2
HCB-B function selection
S2.3
HCB-B function selection
S2.4
For test
S2.5
HCB-B function selection
S2.6
HCB-B function selection
The HCB-B provides nine functions, which can be set according to the following table.
Table 3-16 Function setting of the HCB-B
HCB-B Function S2.6 S2.5 S2.3 S2.2
1. HCB-B function OFF OFF ON OFF
2. Binary output OFF OFF OFF ON
3. 7-segment function OFF OFF OFF OFF
