Moog MSD Specification

Specification TWINsync module
11
3 Installation
ID no.: CB08759-001Date: 03/2023
moog
Plug 1
Pin no.
Cable
Plug 2
Pin no.
1 SYNC IN- SYNC OUT- 2
2 SYNC OUT- SYNC IN- 1
3 GND GND 3
4 RX+ TX+ 5
5 TX+ RX+ 4
6 SYNC IN+ SYNC OUT+ 7
7 SYNC OUT+ SYNC IN+ 6
8 RX- TX- 9
9 TX- RX- 8
Table 3.2: TWINsync connecting cable plug/pin assignment
3.2 TWINsync connecting cable technical data
TWINsync connecting cable
Article designation
Cable length
Connections
Cross-section
CB36987-xxx-yyy
1m
2xSUB-D 9-pin male
4x2x0.25+2x0.50
Table 3.3: Connecting cable technical data and article description
