2 - 4 MC45 Integrator Guide
Single Slot Charge Cradle
This section describes how to set up and use a Single Slot Charge Cradle with the MC45. The Single Slot
Charge Cradle:
Provides 5.0 VDC power for operating the MC45.
Charges the MC45’s battery.
Setup
Figure 2-2
Single Slot Charge Cradle Power Connections
Charging the MC45 Battery
Connect the cradle to the Power Supply as shown in Figure 2-2. Insert the MC45 into the cradle slot to begin
charging.
Figure 2-3
MC45 Battery Charging
USB Rapid
Charge Cable
Power Port
Power Supply
NOTE Use the MC45 micro USB port when charging a completely depleted battery. See Battery Charging on
page 2-17 for more information.
Charging/Battery Status
LED
