Specifications A - 5
Decode Zone
SE965
Figure A-1 shows the decode zone for the SE965. Typical values appear. Table lists the typical distances for
selected bar code densities. The minimum element width (or “symbol density”) is the width in mils of the
narrowest element (bar or space) in the symbol.
Figure A-1
SE965 Decode Zone
47° Scan Angle
Adaptive Scanning Angle (10°)
Note: Typical performance at 73.4° F (23° C)
on high quality symbols.
5 mil C128
5 mil Code 39
7.5 mil
1.2
7.7
1.2
1.1
12.5
18.5
19.0
1.2
1.6
1.0
10 mil Code 128
100% UPC
15 mil Code 128
27.0
29.5
20 mil
55 mil
1.4
3.4*
52.0
100.0**
200.0**
25
100 mil Reflective
In . cm
30 76.2
25 63.5
20 50.8
15 38.1
10 25.4
5 12.7
0 0
5 12.7
10 25.4
15 38.1
20 50.8
25 63.5
30 76.2
50 55 60
35 40 45
20 25 30
5 10 15
In .
cm
0
0
12.7 25.4 38.1 50.8 63.5 76.2 88.9 101.6 114.3 127.0 139.7 152.4
Depth of Field
* Minimum distance determined by symbol length and scan angle
** Distances achieved using adaptive scanning mode.
W
i
d
t
h
o
f
F
i
e
l
d
