Appendix A Technical Specifications
Technical Specifications
The following tables summarizes the intended operating environment and technical hardware specifications for the
MC75A and accessories.
MC75A
Table A-1
MC75A Technical Specifications
Item Description
Physical Characteristics
Dimensions MC75A0:
Length: 15.2 cm (6.00 in.)
Width: 8.4 cm (3.30 in.)
Depth: 4.4 cm (1.70 in.)
MC75A6/8:
Length: 17.78 cm (7.0 in.)
Width: 8.4 cm (3.30 in.)
Depth: 4.4 cm (1.70 in.)
Weight MC75A0:
364 g (12.84 oz) - with 1950 mAh battery
398g (14.04 oz) - with 3600 mAh battery
MC75A6/8:
389 g (13.72 oz) - with 1950 mAh battery
423 g (14.92 oz) - with 3600 mAh battery
Display Transflective color 3.5” VGA with backlight, TFT-LCD, 65K colors,
480 W x 640 L (VGA size)
Note 1: Total output power can be either USB or serial or a combination of both that cannot exceed 200 mA.
