A - 4 MC75A Enterprise Digital Assistant Integrator Guide
MC75A COM Port Definitions
Shock 2,000 +/- 5% G
Scan Rate 50 (+/- 6) scans/sec (bidirectional)
Scan Angle 46.5° (typical)
Laser Power 1.0 mW nominal
2D Imager Engine (SE4500) Specifications
Field of View Horizontal - 40°
Vertical - 25°
Optical Resolution 752X 480 V pixels (gray scale)
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light 9,000 ft. candles (96,900 Lux)
Shock 2,000 +/- 5% G
Focal Distance from Front of
Engine
Near: 5 inches
Far: 9 inches
Aiming Element (VLD) 655 nm +/- 10 nm
Illumination Element (LED) 625 nm +/- 5 nm
Camera Specifications
Resolution 2 Mega pixel with auto focus and flash
Table A-1
MC75A Technical Specifications (Continued)
Item Description
Note 1: Total output power can be either USB or serial or a combination of both that cannot exceed 200 mA.
Table A-2
MC75A COM Port Definitions
COM Port Definition
COM0 Available
COM1 Accessory port
COM2 Available
COM3 IRComm
COM4 Raw IrDA
