Maintenance 6 - 37
Table 6-5 Transceiver Parts List
Item No. Description Part Number
1 Chassis 27012003001
2 Gasket, Enhanced Control Head 3202620Y01
3 Screw, (M2X0.4) 0378341A01
4 SIM dust cover plate 64012011001
5 SIM dust cover 32012066001
6 Pre-driver heat sink thermal pad 75012083001
7 RF PA thermal pad 75012082001
8 GPS cable 3015953H01
9 Main PCB (Item 10 – 12 included) Refer to APPENDIX A –
Replacement Parts & Kits
10 BNC antenna connector
1
1. Non-field replaceable. Change main PCB.
0986166B03
11 Power connector
1
0986165B06
12 Accessory Connector
1
0916017H01
13 TORX 20 Screw with O-ring, 9X (M4X0.7) 0104023J41
14 Connector assembly 0178042A01
15 Retainer clip, 2X 4285702E01
16 Filler pad 75012050001
17 Pressure pad 75012088001
18 Chassis cover gasket 32012065001
19 Chassis cover 27012002001
20 Anti-tamper label 54012082001
21 Cover, plastic 15012064001
CAUTION: The following parts MUST be replaced every time the radio is
disassembled:
• Pre-driver heat sink thermal pad (part number: 75012083001)
– 2pcs.
• RF PA thermal pad (part number: 75012082001)
– 1pc.
!
