Appendix A
LED Indications
Table 32: LED Status Indications
Indication Status
Solid green
• In use
• Repeating call
Blinking green
• In service or idle
• Switching modes from TMO to DMO
Solid red
• Out of service
Blinking red
• Connecting to the network
• Switching modes from DMO to TMO
Solid orange
• Radio is powering up
• Transmit inhibit in service
• Channel busy in DMO
• Radio interference in DMO
Blinking orange Incoming call
No indication
• Radio powered down
• Radio in Covert Mode
Table 33: Battery Charging LED Indications
Indication Status
Solid green Battery fully charged
Blinking green Battery charged at 90%
Solid red Rapid or trickle charge
Blinking red Faulty or invalid battery
Blinking orange Battery is waiting to charge
NOTE:
When you charge your radio in a multi-unit charger and the battery is at the 90–100% charge
level, the LED indicators on the radio and on the multi-unit charger differs:
• LED on the radio – blinking green.
• LED on the multi-unit charger – solid green.
If you insert a radio with a deeply discharged battery into the multi-unit charger, the LED on the
radio shows blinking red, indicating a charging error. Resolve this error by reinserting the radio.
MN006260A01-AG
LED Indications
175
