Annotation Description
• Boot Programming / USB Data Cable Ex, PMKN4158_
• Serial Data Cable Ex, PMKN4159_
• USB Data Cable Ex, PMKN4160_
• E2EE KVL Cable Ex, PMKN4161_
NOTE: It is recommended to turn off the radio before connecting
accessories.
18 Menu key
• From the home screen, press to enter the main menu.
• Used to enter context-sensitive menus.
19 Speaker
20 On/Off/End/Home key
• Press and hold to turn on/off your radio.
• Press to end calls.
• Press to return to the home screen.
21 Navigation key
Press Up, Down, Left, or Right Navigation key for list scrolling, while moving
around the menu hierarchy, or for alphanumeric text editing.
From the home screen, press to activate one of the following:
• Down Navigation key – enters Recent Calls menu item.
• Up Navigation key – changes My Groups talkgroup folder.
• Left and Right Navigation key – toggles through the talkgroups.
2.3
Powering On the Radio
Procedure:
Press and hold On button.
Your radio performs a self-check and registration routine.
After successful registration, your radio is in service.
NOTE: Your radio powers on without visible and audible notification if Covert Mode is activated.
2.4
Writing Text
This section provides information on entering texts on your radio.
2.4.1
Text Entry Icons
In the text entry screen, icons tell you which text entry mode and method you are using. A character
counter displayed on the text entry icon indicates the amount of characters that can be entered.
MN006260A01-AG
Chapter 2 : Getting Started
35
