IMPORTANT: Ensure that the latch on the SIM/microSD door is locked in place before
placing the battery into the radio.
Figure 5: SIM/microSD Door Latch
8 Install the battery and attach the battery cover.
2.2.4
Removing the SIM Card
Procedure:
1 Remove the battery cover and battery.
2 Flip open the SIM/microSD door of the radio.
Figure 6: Opening the SIM/microSD Door
3 Slide up and unlock the SIM connector door (as indicated by the arrow engraved on the SIM
connector door).
4 Flip open the SIM connector door.
Figure 7: Opening the SIM Connector Door
5 Remove the SIM card from the SIM connector slot.
MN002958A01-AF
Chapter 2: Getting Started
17
