Icon Description
• For the manually entered private number,
• When transmitting voice in Group Calls,
• When transmitting voice in Simplex Private Calls.
Blinking, when E2EE is enabled:
• When receiving voice in Group Calls,
• When receiving voice in Simplex Private Calls,
• During encrypted Duplex Private Calls.
Encryption Off
Blinking – Indicates that the SIM Card End-to-End Encryption is disabled in
DMO and TMO Modes.
SIM End-to-End Encryption (E2EE)
Solid – Indicates that the SIM Card E2EE is enabled in TMO Mode.
or
SIM End-to-End Encryption (E2EE)
Solid – Indicates that the SIM Card E2EE is enabled in DMO Mode. Num-
bers 1 and 2 point to the type of DMO Encryption keys that has been select-
ed.
Non-Secured Call – Air Encryption Unavailable
Blinking – Indicates that Air Encryption is not available when the radio:
• Is in the Local Site Trunking Mode.
• Attempts to connect to a gateway.
Non-Secured Call – Air Encryption Unavailable
Blinking – Indicates that Air Encryption is not available in DMO Mode. The
icon appears after the PTT button is pressed.
2.8
Holding Your Radio
Your radio has two microphones: a top microphone for simplex dispatcher/private calls and a bottom
microphone for duplex telephone-like calls.
The radio is also equipped with an internal speaker for high audio (located at the middle of the unit)
and an internal earpiece for low audio (located at the top of the unit).
NOTICE: For best performance speak directly into the top microphone.
Simplex Calls
When using high audio, hold your radio a vertical position with its top microphone 5–10 cm away from
your mouth. Speak into the top microphone. Listen through the internal speaker. Keep the antenna at
least 2.5 cm from your head and body.
MN002958A01-AF
Chapter 2: Getting Started
31
