Annotation Description
7 Audio Connector
The 3.5 mm audio connector supports headset audio and microphone, and PTT
on Motorola Solutions accessories.
8 USB Connector
The USB Type-C
™
connector supports charging and programming.
9 Top Microphone
The Top Microphone is activated during high-audio simplex calls.
NOTICE: When an active KVL device is connected to the radio using the
USB connector, the radio draws current consumption from the KVL device
and starts charging.
10 Talkgroup Selector
The Talkgroup Selector has the following functions:
• Turns on the display when toggled once. Subsequent toggling allows you to
scroll through the talkgroups of the current selected folder on the Idle screen.
• Scrolls through text in the dialing and messaging editors.
NOTICE: The Talkgroup Selector is unlocked when the radio screen is
active.
11 Hybrid Antenna
12 LED Coverage Indicator
Shows the coverage status while the radio is transmitting and receiving over the
network.
13 Earpiece
The Earpiece is active during low-audio simplex or duplex calls.
14 Proximity Sensor
Disables the display and Touch User Interface during full duplex calls to avoid
unintended presses on the touch buttons.
15 PMOLED Display
The 1.54-inch screen features a monochrome display with a resolution of 128 x
64 pixels. The screen consists of a two-line display area with the top line showing
radio icons and the bottom line showing text.
16 Touch User Interface
The four touch sensitive menu icons allow you to navigate the menu.
Up or Down menu icon
Used to navigate within the menu hierarchy or to edit alphanumeric text in the di-
aling and messaging editors.
Back menu icon
The Back button has the following functions:
• Returns to the previous menu or deletes the last entered character in the dial-
ing and messaging editors when pressed once.
• In the dialing and messaging editors, pressing and holding the button clears
the entire main text area.
MN002958A01-AF
Chapter 2: Getting Started
26
