ioLogik E1200 Series Active OPC Server
5-7
Main Screen Overview
Active OPC Server Lite’s main screen displays a figure of the mapped iologik with the status of every I/O tag.
Note that configuration and tags are not available until you set the ioLogik to create the tags.
1. Title
2. Menu bar
3. Quick link
4. Navigation panel
5. Tag Window
6. Log Monitor
7. Status bar
Menu Bar
File
From the File menu, you can export the list of the ioLogik devices currently
displayed in the navigation panel, and import a list into Active OPC Server.
The file will have .mdb and .xls extensions, which can be opened using Microsoft Office Access or Microsoft
Excel. The server list includes the current tag information of the mapped ioLogik.
