ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-5
Reference
Address
Data Type
Description
30046
0x002D
1 word
CH14 DI Counter Value Lo- Word (Read only)
30047
0x002E
1 word
CH15 DI Counter Value Hi- Word (Read only)
30048
0x002F
1 word
CH15 DI Counter Value Lo- Word (Read only)
30049
0x0030
1 word
DI Value (Ch0–15)
Bit0 = Ch0 DI Value (0=OFF, 1=ON)
………
Bit15 = Ch15 DI Value (0=OFF, 1=ON)
E1211 Modbus Mapping
0xxxx Read/Write Coils (Functions 1, 5, 15)
Reference
Address
Data Type
Description
00001
0x0000
1 bit
CH0 DO Value 0: Off 1: On
00002
0x0001
1 bit
CH1 DO Value 0: Off 1: On
00003
0x0002
1 bit
CH2 DO Value 0: Off 1: On
00004
0x0003
1 bit
CH3 DO Value 0: Off 1: On
00005
0x0004
1 bit
CH4 DO Value 0: Off 1: On
00006
0x0005
1 bit
CH5 DO Value 0: Off 1: On
00007
0x0006
1 bit
CH6 DO Value 0: Off 1: On
00008
0x0007
1 bit
CH7 DO Value 0: Off 1: On
00009
0x0008
1 bit
CH8 DO Value 0: Off 1: On
00010
0x0009
1 bit
CH9 DO Value 0: Off 1: On
00011
0x000A
1 bit
CH10 DO Value 0: Off 1: On
00012
0x000B
1 bit
CH11 DO Value 0: Off 1: On
00013
0x000C
1 bit
CH12 DO Value 0: Off 1: On
00014
0x000D
1 bit
CH13 DO Value 0: Off 1: On
00015
0x000E
1 bit
CH14 DO Value 0: Off 1: On
00016
0x000F
1 bit
CH15 DO Value 0: Off 1: On
00017
0x0010
1 bit
CH0 DO Pulse Operate Status 0: Off 1: On
00018
0x0011
1 bit
CH1 DO Pulse Operate Status 0: Off 1: On
00019
0x0012
1 bit
CH2 DO Pulse Operate Status 0: Off 1: On
00020
0x0013
1 bit
CH3 DO Pulse Operate Status 0: Off 1: On
00021
0x0014
1 bit
CH4 DO Pulse Operate Status 0: Off 1: On
00022
0x0015
1 bit
CH5 DO Pulse Operate Status 0: Off 1: On
00023
0x0016
1 bit
CH6 DO Pulse Operate Status 0: Off 1: On
00024
0x0017
1 bit
CH7 DO Pulse Operate Status 0: Off 1: On
00025
0x0018
1 bit
CH8 DO Pulse Operate Status 0: Off 1: On
00026
0x0019
1 bit
CH9 DO Pulse Operate Status 0: Off 1: On
00027
0x001A
1 bit
CH10 DO Pulse Operate Status 0: Off 1: On
00028
0x001B
1 bit
CH11 DO Pulse Operate Status 0: Off 1: On
00029
0x001C
1 bit
CH12 DO Pulse Operate Status 0: Off 1: On
00030
0x001D
1 bit
CH13 DO Pulse Operate Status 0: Off 1: On
00031
0x001E
1 bit
CH14 DO Pulse Operate Status 0: Off 1: On
00032
0x001F
1 bit
CH15 DO Pulse Operate Status 0: Off 1: On
04129
0x1020
1 bit
CH0 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04130
0x1021
1 bit
CH1 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04131
0x1022
1 bit
CH2 DO Clear P2P Output Safe Status Write: 1= clear status
