Moxa Technologies ioLogik E1200 Series User Manual

ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-6
Reference
Address
Data Type
Description
Read: always zero
04132
0x1023
1 bit
CH3 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04133
0x1024
1 bit
CH4 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04134
0x1025
1 bit
CH5 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04135
0x1026
1 bit
CH6 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04136
0x1027
1 bit
CH7 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04137
0x1028
1 bit
CH8 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04138
0x1029
1 bit
CH9 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04139
0x102A
1 bit
CH10 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04140
0x102B
1 bit
CH11 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04141
0x102C
1 bit
CH12 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04142
0x102D
1 bit
CH13 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04143
0x102E
1 bit
CH14 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04144
0x102F
1 bit
CH15 DO Clear P2P Output Safe Status Write: 1= clear status
Read: always zero
04145
0x1030
1 bit
Clear Watchdog Alarm
1xxxx Read Only Coils (Function 2)
Reference
Address
Data Type
Description
14097
0x1000
1 bit
CH0 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14098
0x1001
1 bit
CH1 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14099
0x1002
1 bit
CH2 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14100
0x1003
1 bit
CH3 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14101
0x1004
1 bit
CH4 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14102
0x1005
1 bit
CH5 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14103
0x1006
1 bit
CH6 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14104
0x1007
1 bit
CH7 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14105
0x1008
1 bit
CH8 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14106
0x1009
1 bit
CH9 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14107
0x100A
1 bit
CH10 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14108
0x100B
1 bit
CH11 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14109
0x100C
1 bit
CH12 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14110
0x100D
1 bit
CH13 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14111
0x100E
1 bit
CH14 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14112
0x100F
1 bit
CH15 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14113
0x1010
1 bit
CH0 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
14114
0x1011
1 bit
CH1 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
14115
0x1012
1 bit
CH2 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
14116
0x1013
1 bit
CH3 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
