ioLogik E1200 Series Modbus/TCP Default Address Mappings

A-7

Reference

Address

Data Type

Description

14117

0x1014

1 bit

CH4 DO P2P Output Safe Status 0=Normal, 1=Safe Mode

14118

0x1015

1 bit

CH5 DO P2P Output Safe Status 0=Normal, 1=Safe Mode

14119

0x1016

1 bit

CH6 DO P2P Output Safe Status 0=Normal, 1=Safe Mode

14120

0x1017

1 bit

CH7 DO P2P Output Safe Status 0=Normal, 1=Safe Mode

14121

0x1018

1 bit

CH8 DO P2P Output Safe Status 0=Normal, 1=Safe Mode

14122

0x1019

1 bit

CH9 DO P2P Output Safe Status 0=Normal, 1=Safe Mode

14123

0x101A

1 bit

CH10 DO P2P Output Safe Status 0=Normal, 1=Safe Mode

14124

0x101B

1 bit

CH11 DO P2P Output Safe Status 0=Normal, 1=Safe Mode

14125

0x101C

1 bit

CH12 DO P2P Output Safe Status 0=Normal, 1=Safe Mode

14126

0x101D

1 bit

CH13 DO P2P Output Safe Status 0=Normal, 1=Safe Mode

14127

0x101E

1 bit

CH14 DO P2P Output Safe Status 0=Normal, 1=Safe Mode

14128

0x101F

1 bit

CH15 DO P2P Output Safe Status 0=Normal, 1=Safe Mode

E1212 Modbus Mapping

0xxxx Read/Write Coils (Functions 1, 5, 15)

Reference

Address

Data Type

Description

DO Channel

00001

0x0000

1 bit

CH0 DO Value 0: Off 1: On

00002

0x0001

1 bit

CH1 DO Value 0: Off 1: On

00003

0x0002

1 bit

CH2 DO Value 0: Off 1: On

00004

0x0003

1 bit

CH3 DO Value 0: Off 1: On

00005

0x0004

1 bit

CH4 DO Value 0: Off 1: On

00006

0x0005

1 bit

CH5 DO Value 0: Off 1: On

00007

0x0006

1 bit

CH6 DO Value 0: Off 1: On

00008

0x0007

1 bit

CH7 DO Value 0: Off 1: On

00017

0x0010

1 bit

CH0 DO Pulse Operate Status 0: Off 1: On

00018

0x0011

1 bit

CH1 DO Pulse Operate Status 0: Off 1: On

00019

0x0012

1 bit

CH2 DO Pulse Operate Status 0: Off 1: On

00020

0x0013

1 bit

CH3 DO Pulse Operate Status 0: Off 1: On

00021

0x0014

1 bit

CH4 DO Pulse Operate Status 0: Off 1: On

00022

0x0015

1 bit

CH5 DO Pulse Operate Status 0: Off 1: On

00023

0x0016

1 bit

CH6 DO Pulse Operate Status 0: Off 1: On

00024

0x0017

1 bit

CH7 DO Pulse Operate Status 0: Off 1: On

DI Channel

00257

0x0100

1 bit

CH0 DI Counter Operate Status 0: Stop 1: Start(R/W)

00258

0x0101

1 bit

CH1 DI Counter Operate Status 0: Stop 1: Start(R/W)

00259

0x0102

1 bit

CH2 DI Counter Operate Status 0: Stop 1: Start(R/W)

00260

0x0103

1 bit

CH3 DI Counter Operate Status 0: Stop 1: Start(R/W)

00261

0x0104

1 bit

CH4 DI Counter Operate Status 0: Stop 1: Start(R/W)

00262

0x0105

1 bit

CH5 DI Counter Operate Status 0: Stop 1: Start(R/W)

00263

0x0106

1 bit

CH6 DI Counter Operate Status 0: Stop 1: Start(R/W)

00264

0x0107

1 bit

CH7 DI Counter Operate Status 0: Stop 1: Start(R/W)

00265

0x0108

1 bit

CH8 DI Counter Operate Status 0: Stop 1: Start(R/W)

00266

0x0109

1 bit

CH9 DI Counter Operate Status 0: Stop 1: Start(R/W)

00267

0x010A

1 bit

CH10 DI Counter Operate Status 0: Stop 1: Start(R/W)

00268

0x010B

1 bit

CH11 DI Counter Operate Status 0: Stop 1: Start(R/W)

00269

0x010C

1 bit

CH12 DI Counter Operate Status 0: Stop 1: Start(R/W)

00270

0x010D

1 bit

CH13 DI Counter Operate Status 0: Stop 1: Start(R/W)
