Moxa Technologies ioLogik E1200 Series User Manual

ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-18
3xxxx Read Only Registers (Function 4)
Reference
Address
Data Type
Description
30017
0x0010
1 word
CH0 DI Counter Value Hi- Word (Read only)
30018
0x0011
1 word
CH0 DI Counter Value Lo- Word (Read only)
30019
0x0012
1 word
CH1 DI Counter Value Hi- Word (Read only)
30020
0x0013
1 word
CH1 DI Counter Value Lo- Word (Read only)
30021
0x0014
1 word
CH2 DI Counter Value Hi- Word (Read only)
30022
0x0015
1 word
CH2 DI Counter Value Lo- Word (Read only)
30023
0x0016
1 word
CH3 DI Counter Value Hi- Word (Read only)
30024
0x0017
1 word
CH3 DI Counter Value Lo- Word (Read only)
30025
0x0018
1 word
CH4 DI Counter Value Hi- Word (Read only)
30026
0x0019
1 word
CH4 DI Counter Value Lo- Word (Read only)
30027
0x001A
1 word
CH5 DI Counter Value Hi- Word (Read only)
30028
0x001B
1 word
CH5 DI Counter Value Lo- Word (Read only)
30049
0x0030
1 word
DI Value (Ch0–5)
Bit0 = Ch0 DI Value (0=OFF, 1=ON)
………
Bit5 = Ch5 DI Value (0=OFF, 1=ON)
4xxxx Read/Write Registers (Functions 3, 6, 16)
Reference
Address
Data Type
Description
40033
0x0020
1 word
DO (Relay) all Value (Ch0–5)
Bit0 = Ch0 DO Value (0=OFF, 1=ON)
………
Bit5 = Ch5 DO Value (0=OFF, 1=ON)
E1240 Modbus Mapping
0xxxx Read/Write Coils (Functions 1, 5, 15)
Reference
Address
Data Type
Description
04145
0x1030
1 bit
Clear Watchdog Alarm
3xxxx Read Only Registers (Function 4)
Reference
Address
Data Type
Description
30001
0x0000
1 word
CH0 Read AI Value
30002
0x0001
1 word
CH1 Read AI Value
30003
0x0002
1 word
CH2 Read AI Value
30004
0x0003
1 word
CH3 Read AI Value
30005
0x0004
1 word
CH4 Read AI Value
30006
0x0005
1 word
CH5 Read AI Value
30007
0x0006
1 word
CH6 Read AI Value
30008
0x0007
1 word
CH7 Read AI Value
30009
0x0008
1 word
CH0 Read AI Scaling Value Hi (float)
30010
0x0009
1 word
CH0 Read AI Scaling Value Low (float)
30011
0x000A
1 word
CH1 Read AI Scaling Value Hi (float)
30012
0x000B
1 word
CH1 Read AI Scaling Value Low (float)
