ioLogik E1200 Series Modbus/TCP Default Address Mappings
The Modbus/TCP ID of the ioLogik E1200 is set to “1” by default.
E1210 Modbus Mapping
0xxxx Read/Write Coils (Functions 1, 5, 15)
CH0 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH1 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH2 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH3 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH4 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH5 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH6 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH7 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH8 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH9 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH10 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH11 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH12 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH13 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH14 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH15 DI Counter Operate Status 0: Stop 1: Start(R/W)
CH0 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
CH1 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
CH2 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
CH3 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
CH4 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
CH5 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
CH6 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
