ioLogik E1200 Series Initial Setup

2-5

I/O Wiring Diagrams

A Dry Contact is a contact that does not provide voltage.

A Wet Contact is a contact that will provide voltage when closed.

ATTENTION

Remove the screw on the back panel and open the cover to configure the jumpers.
