ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-16
E1214 Modbus Mapping
0xxxx Read/Write Coils (Functions 1, 5, 15)
Reference
Address
Data Type
Description
DO Channel
00001
0x0000
1 bit
CH0 DO (Relay) Value 0: Off 1: On
00002
0x0001
1 bit
CH1 DO (Relay) Value 0: Off 1: On
00003
0x0002
1 bit
CH2 DO (Relay) Value 0: Off 1: On
00004
0x0003
1 bit
CH3 DO (Relay) Value 0: Off 1: On
00005
0x0004
1 bit
CH4 DO (Relay) Value 0: Off 1: On
00006
0x0005
1 bit
CH5 DO (Relay) Value 0: Off 1: On
00017
0x0010
1 bit
CH0 DO (Relay) Pulse Operate Status 0: Off 1: On
00018
0x0011
1 bit
CH1 DO (Relay) Pulse Operate Status 0: Off 1: On
00019
0x0012
1 bit
CH2 DO (Relay) Pulse Operate Status 0: Off 1: On
00020
0x0013
1 bit
CH3 DO (Relay) Pulse Operate Status 0: Off 1: On
00021
0x0014
1 bit
CH4 DO (Relay) Pulse Operate Status 0: Off 1: On
00022
0x0015
1 bit
CH5 DO (Relay) Pulse Operate Status 0: Off 1: On
04129
0x1020
1 bit
CH0 DO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
04130
0x1021
1 bit
CH1 DO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
04131
0x1022
1 bit
CH2 DO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
04132
0x1023
1 bit
CH3 DO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
04133
0x1024
1 bit
CH4 DO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
04134
0x1025
1 bit
CH5 DO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
DI Channel
00257
0x0100
1 bit
CH0 DI Counter Operate Status 0: Stop 1: Start(R/W)
00258
0x0101
1 bit
CH1 DI Counter Operate Status 0: Stop 1: Start(R/W)
00259
0x0102
1 bit
CH2 DI Counter Operate Status 0: Stop 1: Start(R/W)
00260
0x0103
1 bit
CH3 DI Counter Operate Status 0: Stop 1: Start(R/W)
00261
0x0104
1 bit
CH4 DI Counter Operate Status 0: Stop 1: Start(R/W)
00262
0x0105
1 bit
CH5 DI Counter Operate Status 0: Stop 1: Start(R/W)
00273
0x0110
1 bit
CH0 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00274
0x0111
1 bit
CH1 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00275
0x0112
1 bit
CH2 DI Clear Count Value
