Moxa Technologies ioLogik E1200 Series User Manual

ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-20
3xxxx Read Only Registers (Function 4)
Reference
Address
Data Type
Description
40025
0x0018
1 word
CH AI 0 Mode: 1:4-20mA, 2:0-20mA, 4:BO
40026
0x0019
1 word
CH AI 1 Mode: 1:4-20mA, 2:0-20mA, 4:BO
40027
0x001A
1 word
CH AI 2 Mode: 1:4-20mA, 2:0-20mA, 4:BO
40028
0x001B
1 word
CH AI 3 Mode: 1:4-20mA, 2:0-20mA, 4:BO
40029
0x001C
1 word
CH AI 4 Mode: 1:4-20mA, 2:0-20mA, 4:BO
40030
0x001D
1 word
CH AI 5 Mode: 1:4-20mA, 2:0-20mA, 4:BO
40031
0x001E
1 word
CH AI 6 Mode: 1:4-20mA, 2:0-20mA, 4:BO
40032
0x001F
1 word
CH AI 7 Mode: 1:4-20mA, 2:0-20mA, 4:BO
40041
0x0028
2 words
CH AI 0 BO Value (floating point)
40043
0x002A
2 words
CH AI 1 BO Value (floating point)
40045
0x002C
2 words
CH AI 2 BO Value (floating point)
40047
0x002E
2 words
CH AI 3 BO Value (floating point)
40049
0x0030
2 words
CH AI 4 BO Value (floating point)
40051
0x0032
2 words
CH AI 5 BO Value (floating point)
40053
0x0034
2 words
CH AI 6 BO Value (floating point)
40055
0x0036
2 words
CH AI 7 BO Value (floating point)
E1241 Modbus Mapping
0xxxx Read/Write Coils (Functions 1, 5, 15)
Reference
Address
Data Type
Description
04129
0x1020
1 bit
CH0 AO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
04130
0x1021
1 bit
CH1 AO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
04131
0x1022
1 bit
CH2 AO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
04132
0x1023
1 bit
CH3 AO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
04145
0x1030
1 bit
Clear Watchdog Alarm
1xxxx Read Only Coils (Function 2)
Reference
Address
Data type
Description
14097
0x1000
1 bit
CH0 AO P2P Connect Status 0=OFFLINE, 1=ONLINE
14098
0x1001
1 bit
CH1 AO P2P Connect Status 0=OFFLINE, 1=ONLINE
14099
0x1002
1 bit
CH2 AO P2P Connect Status 0=OFFLINE, 1=ONLINE
14100
0x1003
1 bit
CH3 AO P2P Connect Status 0=OFFLINE, 1=ONLINE
14113
0x1010
1 bit
CH0 AO P2P Output Safe Status 0=Normal, 1=Safe Mode
14114
0x1011
1 bit
CH1 AO P2P Output Safe Status 0=Normal, 1=Safe Mode
14115
0x1012
1 bit
CH2 AO P2P Output Safe Status 0=Normal, 1=Safe Mode
14116
0x1013
1 bit
CH3 AO P2P Output Safe Status 0=Normal, 1=Safe Mode
