Moxa Technologies ioLogik E1200 Series User Manual

ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-21
3xxxx Read Only Registers (Function 4)
Reference
Address
Data Type
Description
30001
0x0000
2 words
CH0 Read AO Scaling Value (float)
30002
0x0001
2 words
CH1 Read AO Scaling Value (float)
30003
0x0002
2 words
CH2 Read AO Scaling Value (float)
30004
0x0003
2 words
CH3 Read AO Scaling Value (float)
4xxxx Read/Write Registers (Functions 3, 6, 16)
Reference
Address
Data Type
Description
41025
0x0400
1 word
CH0 AO RAW Value
41026
0x0401
1 word
CH1 AO RAW Value
41027
0x0402
1 word
CH2 AO RAW Value
41028
0x0403
1 word
CH3 AO RAW Value
E1242 Modbus Mapping
0xxxx Read/Write Coils (Functions 1, 5, 15)
Reference
Address
Data Type
Description
DO Channel
00001
0x0000
1 bit
CH0 DO Value 0: Off 1: On
00002
0x0001
1 bit
CH1 DO Value 0: Off 1: On
00003
0x0002
1 bit
CH2 DO Value 0: Off 1: On
00004
0x0003
1 bit
CH3 DO Value 0: Off 1: On
00017
0x0010
1 bit
CH0 DO Pulse Operate Status 0: Off 1: On
00018
0x0011
1 bit
CH1 DO Pulse Operate Status 0: Off 1: On
00019
0x0012
1 bit
CH2 DO Pulse Operate Status 0: Off 1: On
00020
0x0013
1 bit
CH3 DO Pulse Operate Status 0: Off 1: On
DI Channel
00257
0x0100
1 bit
CH0 DI Counter Operate Status 0: Stop 1: Start(R/W)
00258
0x0101
1 bit
CH1 DI Counter Operate Status 0: Stop 1: Start(R/W)
00259
0x0102
1 bit
CH2 DI Counter Operate Status 0: Stop 1: Start(R/W)
00260
0x0103
1 bit
CH3 DI Counter Operate Status 0: Stop 1: Start(R/W)
00261
0x0104
1 bit
CH4 DI Counter Operate Status 0: Stop 1: Start(R/W)
00262
0x0105
1 bit
CH5 DI Counter Operate Status 0: Stop 1: Start(R/W)
00263
0x0106
1 bit
CH6 DI Counter Operate Status 0: Stop 1: Start(R/W)
00264
0x0107
1 bit
CH7 DI Counter Operate Status 0: Stop 1: Start(R/W)
00273
0x0110
1 bit
CH0 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00274
0x0111
1 bit
CH1 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00275
0x0112
1 bit
CH2 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
