Moxa Technologies ioLogik E1200 Series User Manual

ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-12
E1213 Modbus Mapping
0xxxx Read/Write Coils (Functions 1, 5, 15)
Reference
Address
Data Type
Description
DO Channel
00001
0x0000
1 bit
CH0 DO Value 0: Off 1: On
00002
0x0001
1 bit
CH1 DO Value 0: Off 1: On
00003
0x0002
1 bit
CH2 DO Value 0: Off 1: On
00004
0x0003
1 bit
CH3 DO Value 0: Off 1: On
00005
0x0004
1 bit
CH4 DO Value 0: Off 1: On
00006
0x0005
1 bit
CH5 DO Value 0: Off 1: On
00007
0x0006
1 bit
CH6 DO Value 0: Off 1: On
00008
0x0007
1 bit
CH7 DO Value 0: Off 1: On
00017
0x0010
1 bit
CH0 DO Pulse Operate Status 0: Off 1: On
00018
0x0011
1 bit
CH1 DO Pulse Operate Status 0: Off 1: On
00019
0x0012
1 bit
CH2 DO Pulse Operate Status 0: Off 1: On
00020
0x0013
1 bit
CH3 DO Pulse Operate Status 0: Off 1: On
00021
0x0014
1 bit
CH4 DO Pulse Operate Status 0: Off 1: On
00022
0x0015
1 bit
CH5 DO Pulse Operate Status 0: Off 1: On
00023
0x0016
1 bit
CH6 DO Pulse Operate Status 0: Off 1: On
00024
0x0017
1 bit
CH7 DO Pulse Operate Status 0: Off 1: On
DI Channel
00257
0x0100
1 bit
CH0 DI Counter Operate Status
0: Stop 1: Start (R/W)
00258
0x0101
1 bit
CH1 DI Counter Operate Status
0: Stop 1: Start (R/W)
00259
0x0102
1 bit
CH2 DI Counter Operate Status
0: Stop 1: Start (R/W)
00260
0x0103
1 bit
CH3 DI Counter Operate Status
0: Stop 1: Start (R/W)
00261
0x0104
1 bit
CH4 DI Counter Operate Status
0: Stop 1: Start (R/W)
00262
0x0105
1 bit
CH5 DI Counter Operate Status
0: Stop 1: Start (R/W)
00263
0x0106
1 bit
CH6 DI Counter Operate Status
0: Stop 1: Start (R/W)
00264
0x0107
1 bit
CH7 DI Counter Operate Status
0: Stop 1: Start (R/W)
00265
0x0108
1 bit
CH8 DI Counter Operate Status
0: Stop 1: Start (R/W)
00266
0x0109
1 bit
CH9 DI Counter Operate Status
0: Stop 1: Start (R/W)
00267
0x010A
1 bit
CH10 DI Counter Operate Status
0: Stop 1: Start (R/W)
00268
0x010B
1 bit
CH11 DI Counter Operate Status
0: Stop 1: Start (R/W)
00273
0x0110
1 bit
CH0 DI Clear Count Value
Read Always return: 0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00274
0x0111
1 bit
CH1 DI Clear Count Value
