Moxa Technologies ioLogik E1200 Series User Manual

ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-22
Reference
Address
Data Type
Description
00276
0x0113
1 bit
CH3 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00277
0x0114
1 bit
CH4 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00278
0x0115
1 bit
CH5 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00279
0x0116
1 bit
CH6 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00280
0x0117
1 bit
CH7 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
04129
0x1020
1 bit
CH0 DO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
04130
0x1021
1 bit
CH1 DO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
04131
0x1022
1 bit
CH2 DO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
04132
0x1023
1 bit
CH3 DO Clear P2P Output Safe Status
Write: 1= clear status
Read: always zero
04145
0x1030
1 bit
Clear Watchdog Alarm
1xxxx Read Only Coils (Function 2)
Reference
Address
Data Type
Description
DI Channel
10001
0x0000
1 bit
CH0 DI Value, 0=OFF, 1=ON (Read only)
10002
0x0001
1 bit
CH1 DI Value, 0=OFF, 1=ON (Read only)
10003
0x0002
1 bit
CH2 DI Value, 0=OFF, 1=ON (Read only)
10004
0x0003
1 bit
CH3 DI Value, 0=OFF, 1=ON (Read only)
10005
0x0004
1 bit
CH4 DI Value, 0=OFF, 1=ON (Read only)
10006
0x0005
1 bit
CH5 DI Value, 0=OFF, 1=ON (Read only)
10007
0x0006
1 bit
CH6 DI Value, 0=OFF, 1=ON (Read only)
10008
0x0007
1 bit
CH7 DI Value, 0=OFF, 1=ON (Read only)
14097
0x1000
1 bit
CH0 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14098
0x1001
1 bit
CH1 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14099
0x1002
1 bit
CH2 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14100
0x1003
1 bit
CH3 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14113
0x1010
1 bit
CH0 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
14114
0x1011
1 bit
CH1 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
