ioLogik E1200 Series Modbus/TCP Default Address Mappings
CH2 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
CH3 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
3xxxx Read Only Registers (Function 4)
CH0 DI Counter Value Hi- Word (Read only)
CH0 DI Counter Value Lo- Word (Read only)
CH1 DI Counter Value Hi- Word (Read only)
CH1 DI Counter Value Lo- Word (Read only)
CH2 DI Counter Value Hi- Word (Read only)
CH2 DI Counter Value Lo- Word (Read only)
CH3 DI Counter Value Hi- Word (Read only)
CH3 DI Counter Value Lo- Word (Read only)
CH4 DI Counter Value Hi- Word (Read only)
CH4 DI Counter Value Lo- Word (Read only)
CH5 DI Counter Value Hi- Word (Read only)
CH5 DI Counter Value Lo- Word (Read only)
CH6 DI Counter Value Hi- Word (Read only)
CH6 DI Counter Value Lo- Word (Read only)
CH7 DI Counter Value Hi- Word (Read only)
CH7 DI Counter Value Lo- Word (Read only)
DI Value (Ch0–7)
Bit0 = Ch0 DI Value (0=OFF, 1=ON)
Bit7 = Ch7 DI Value (0=OFF, 1=ON) ………
Bit8 to 15 = reserved
CH0 Read AI Scaling Value Hi (float)
CH0 Read AI Scaling Value Low (float)
CH1 Read AI Scaling Value Hi (float)
CH1 Read AI Scaling Value Low (float)
CH2 Read AI Scaling Value Hi (float)
CH2 Read AI Scaling Value Low (float)
CH3 Read AI Scaling Value Hi (float)
CH3 Read AI Scaling Value Low (float)
Read AI 0 Current Mode Status
0: Normal
1: Burn Out
2: Over Range
3. Under Range
Read AI 1 Current Mode Status
0: Normal
1: Burn Out
2: Over Range
3. Under Range
Read AI 2 Current Mode Status
0: Normal
1: Burn Out
