Moxa Technologies ioLogik E1200 Series User Manual

ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-17
Reference
Address
Data Type
Description
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00276
0x0113
1 bit
CH3 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00277
0x0114
1 bit
CH4 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
00278
0x0115
1 bit
CH5 DI Clear Count Value
Read Always return:0
Write: 1 : Clear counter value
0 : Return illegal data value(0x03)
04145
0x1030
1 bit
Clear Watchdog Alarm
1xxxx Read Only Coils (Function 2)
Reference
Address
Data Type
Description
10001
0x0000
1 bit
CH0 DI Value, 0=OFF, 1=ON (Read only)
10002
0x0001
1 bit
CH1 DI Value, 0=OFF, 1=ON (Read only)
10003
0x0002
1 bit
CH2 DI Value, 0=OFF, 1=ON (Read only)
10004
0x0003
1 bit
CH3 DI Value, 0=OFF, 1=ON (Read only)
10005
0x0004
1 bit
CH4 DI Value, 0=OFF, 1=ON (Read only)
10006
0x0005
1 bit
CH5 DI Value, 0=OFF, 1=ON (Read only)
14097
0x1000
1 bit
CH0 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14098
0x1001
1 bit
CH1 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14099
0x1002
1 bit
CH2 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14100
0x1003
1 bit
CH3 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14101
0x1004
1 bit
CH4 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14102
0x1005
1 bit
CH5 DO P2P Connect Status 0=OFFLINE, 1=ONLINE
14113
0x1010
1 bit
CH0 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
14114
0x1011
1 bit
CH1 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
14115
0x1012
1 bit
CH2 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
14116
0x1013
1 bit
CH3 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
14117
0x1014
1 bit
CH4 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
14118
0x1015
1 bit
CH5 DO P2P Output Safe Status 0=Normal, 1=Safe Mode
