ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-18
ioLogik E1262 Modbus Address and Register
Map
I/O
Parameter Name Description Start
Address
(decimal)
Point
Type
Start
Register
(decimal)
Length Access Type
TC CJC TC CJC
calibration
start
4193 01:COIL
STATUS
04194 8 R/W bit
TC refEngValue
(float)
TC calibration
reference
2144 03:HOLDI
NG
REGISTER
42145 8 R/W 2 words
TC_multipliedEngine
eringValue
high/low word,
Unit:0.1
(Celsius,
Fahrenheit) or
0.0001 (mV)
2048 04:INPUT
REGISTER
32049 16 R 2 words
TC_multipliedEngine
eringValueMax
high/low word,
Unit:0.1
(Celsius,
Fahrenheit) or
0.0001 (mV)
2096 04:INPUT
REGISTER
32097 16 R 2 words
TC_multipliedEngine
eringValueMin
high/low word,
Unit:0.1
(Celsius,
Fahrenheit) or
0.0001 (mV)
2080 04:INPUT
REGISTER
32081 16 R 2 words
TC_resetMaxValue 1: reset max.
value
4185 01:COIL
STATUS
04186 8 R/W bit
TC_resetMinValue 1: reset min.
value
4177 01:COIL
STATUS
04178 8 R/W bit
TC_scaledValue high/low word 2064 04:INPUT
REGISTER
32065 16 R 2 words
TC_scaledValueMax high/low word 2128 04:INPUT
REGISTER
32129 16 R 2 words
TC_scaledValueMin high/low word 2112 04:INPUT
REGISTER
32113 16 R 2 words
